Overview
- 48V 13AH Large capacity battery, 48V 2AH safety certificated fast charging
- POWERFUL MOTOR, FRONT FORK SHOCK ABSORBER
- Industrial aluminum, lighter and durable
- Range 80-120km
- Back rack
Key Features
POWERFUL BRUSHLESS REAR HUB MOTOR
A whisper quiet, 500-watt motor delivers best in class acceleration and hill climbing. The sensation of power it gives you is exhilarating
SUPER CHARGED BATTERY
48V 13AH large capacity battery uses the same advanced lithium-ion cells as an electric car. It weighs less than a kitten and can take you up to 100 kilometers on about 10 cents worth of electricity on about 10 cents worth of electricity.
DOUBLE ACTION CABLE DISC BRAKE
Top of the double cable disc brakes stop on a dime with the greatest of ease. The levers are easier to pull than normal disk brakes, and they feel more responsive.
EASY PEDALING
A larger front chainring and deluxe 7-speed drivetrain provide fluid shifting and comfortable pedaling, even at high speeds.
SMOOTH RIDE
A high-end suspension fork allows you to effortlessly glide over bumps in the road. A simple lockout switch saves energy when you don’t need the suspension.
ALL ACCESSORIES INCLUDED, INCLUDING FRONT & REAR FENDERS
You never pay more for accessories like fenders, bells, etc. Our prices include everything you see
Specifications
ELECTRONICS
| MOTOR | 48V 500W BRUSHLESS REAR HUB MOTOR, WITH WATER PROOF WIRES |
| BATTERY | 48V 14 Ah LITHIUM-ION BATTERY, REMOVABLE BATTERY PACK WITH LOCK |
| CHARGER | 90-264V WITH LED LIGHT STATUS DISPLAY, UL & SE CERTIFIED FOR NORTH AMERICA, 5-7 HOURS |
| DISPLAY | LINGHUI LCD SMART INSTRUMENT, 5-SPEED ASSIST FUNCTION, SPEED DISPLAY, WITH LIGHTS SWITCH, TIME DISPLAY, MAX. SPEED, RIDING MILEAGE |
| CONTROLLER | 48V 22A, BRUSHLESS CONTROLLER, WATER PROOF PLUG |
| ELECTRIC CABLES | WATERPROOF WIRE, EASILY DISASSEMBLE/INSTALL |
| BACK LIGHT | LED, FIT ON SEAT POST |
| HEAD LIGHT | LED, WATERPROOF PLUG |
| TOP SPEED | 32KM (20MPH) |
| RIDING RANGE | 40 – 60 KM (25 -37 MILES) |
DRIVETRAIN & BRAKES
| DERAILLEUR | SHIMANO ALLOY, 7 SPEED |
| GEAR | SHIMANO® AMFTZ5107428 FREEWHEEL, 14- 16-18-20-22-24-28T |
| DISC BRAKES | TEKTRO MECHARICAL DISC BRAKES |
| BRAKE HANDLE | ALLOY MATERIAL, ELECTRIC CUT |
| CRANK | ALUMINUM, PROWHEEL |
| PEDALS | FP BRAND, PLASTIC, BALL-BEARING, AS/BS/CPSC REFLECTOR |
COMPONENTS
| FRAME | 6061 ALUMINUM, 26" |
| FORK | ALLOY ALUMINUM WITH SINGLE SUSPENSION, TRAVEL:55MM, POST MOUNT |
| SEAT | HIGH QUALITY & COMFORT SADDLE, BLACK LEATHER |
| SEAT POST | ALLOY ALUMINUM, SAND BLACK, WITH CLAMP, WITH SAFETY LINE |
| TIRES | REGULAR 26 X 2.1", CST BRAND |
| RIMS | DURABLE ALLOY SINGLE WALL RIMS, 26" |
| HANDLEBAR | ALLOY, SAND BLACK, U - TYPE, W:640MM*2.2T |
| HAND GRIPS | HIGH QUALITY RUBBER, BLACK |
| STEM | ALLOY, SAND BLACK, A-HEAD, E:90, H=40, ANGLE: 7 |
| FRONT/REAR FENDERS | BLACK, SHORT PLASTIC |
| HEAD LIGHT | LED, WATERPROOF PLUG |
| KICKSTAND | 6061 ALUMINUM, ADJUSTABLE |
| SPOKE | BLACK, 13G FOR WHEEL, WITH BRASS NIPPLE |
EXTRAS
| WHEEL SIZE | 26” (66CM) |
| BIKES (NO BATTERY) | 23.7KG (52lbs) |
| BATTERY | 3.2KG (7lbs) |
| WEIGHT CAPACITY | 125KG (275Ibs) |
| HEIGHT CAPACITY | 165 CM (5' 4") AND ABOVE |
| CHARING TIME | 5 - 7 HOURS |
