Overview
- 48V 13AH Samsung battery, 48V 2AH safety certificated fast charging
- 500W powerful motor, front fork shock absorber
- Industrial aluminum, lighter and durable
- Battery removable & capacity display
Key Features
POWERFUL BRUSHLESS REAR HUB MOTOR
A whisper quiet, 500-watt motor delivers best in class acceleration and hill climbing. The sensation of power it gives you is exhilarating
LONG RANGE
The 48V 13AH lightweight, long lasting Samsung battery will take you anywhere you want to go – and back.
DOUBLE ACTION CABLE DISC BRAKE
Top of the double cable disc brakes stop on a dime with the greatest of ease. The levers are easier to pull than normal disk brakes, and they feel more responsive.
EASY PEDALING
A larger front chainring and deluxe 7-speed drivetrain provide fluid shifting and comfortable pedaling, even at high speeds.
SMOOTH RIDE
A high-end suspension fork allows you to effortlessly glide over bumps in the road. A simple lockout switch saves energy when you don’t need the suspension.
PEDAL SENSE
Pedal-and-go throttle, 5 levels of pedal assist, and LCD display with USB charger.
Specifications
ELECTRONICS
| MOTOR | 48V 500W BRUSHLESS REAR HUB MOTOR, WITH WATER PROOF WIRES |
| BATTERY | SAMSUNG LITHIUM-ION 48V 13Ah, REMOVABLE BATTERY PACK WITH BATTERY LOCK |
| CHARGER | 90-264V WITH LED LIGHT STATUS DISPLAY, UL & SE CERTIFIED FOR NORTH AMERICA, 5-7 HOURS |
| DISPLAY | LINGHUI LCD SMART INSTRUMENT, 5-SPEED ASSIST FUNCTION, SPEED DISPLAY, WITH LIGHTS SWITCH, TIME DISPLAY, MAX. SPEED, RIDING MILEAGE |
| CONTROLLER | 48V 22A, BRUSHLESS CONTROLLER, WATER PROOF PLUG |
| ELECTRIC CABLES | WATERPROOF WIRE, EASILY DISASSEMBLE/INSTALL |
| BACK LIGHT | LED, FIT ON SEAT POST |
| HEAD LIGHT | LED, WATERPROOF PLUG |
| TOP SPEED | 32KM (20MPH) |
| RIDING RANGE | 40 – 60 KM (25 -37 MILES) |
DRIVETRAIN & BRAKES
| DERAILLEUR | SHIMANO ALLOY, 7 SPEED |
| GEAR | SHIMANO® AMFTZ5107428 FREEWHEEL, 14-16-18-20-22-24-28T |
| DISC BRAKES | TEKTRO MECHARICAL DISC BRAKES |
| BRAKE HANDLE | ALLOY MATERIAL, ELECTRIC CUT |
| CRANK | ALUMINUM, PROWHEEL |
| PEDALS | FP BRAND, PLASTIC, BALL-BEARING, AS/BS/CPSC REFLECTOR |
COMPONENTS
| FRAME | 6061 ALUMINUM, 26" |
| FORK | ALLOY ALUMINUM WITH SINGLE SUSPENSION, TRAVEL:55MM, POST MOUNT |
| SEAT | HIGH QUALITY & COMFORT SADDLE, BLACK LEATHER |
| SEAT POST | ALLOY ALUMINUM, SAND BLACK, WITH CLAMP, WITH SAFETY LINE |
| TIRES | CST REGULAR 26 X 2.1" |
| RIMS | DURABLE ALLOY SINGLE WALL RIMS, 26" |
| HANDLEBAR | ALLOY, SAND BLACK, U - TYPE, W:640MM*2.2T |
| HAND GRIPS | HIGH QUALITY RUBBER, BLACK |
| STEM | ALLOY, SAND BLACK, A-HEAD, E:90, H=40, ANGLE: 7 |
| FRONT/REAR FENDERS | SAND BLACK, SHORT PLASTIC |
| HEAD LIGHT | LED, WATERPROOF PLUG |
| KICKSTAND | 6061 ALUMINUM, ADJUSTABLE |
| SPOKE | BLACK, 13G FOR WHEEL, WITH BRASS NIPPLE |
EXTRAS
| WHEEL SIZE | 26” (66CM) |
| BIKES (NO BATTERY) | 23.7KG (52lbs) |
| BATTERY | 3.2KG (7lbs) |
| WEIGHT CAPACITY | 125KG (275Ibs) |
| HEIGHT CAPACITY | 165 CM (5' 4") AND ABOVE |
| CHARING TIME | 5 - 7 HOURS |
